TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB
$425
Description
TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB
Dimensions
d - Bore
12.00 mm0.4724 in
D - Outer Diameter
32.00 mm1.2598 in
Bearing Width
10.00 mm0.3937 in
Contact Angle
25 º
do - Ball Diameter
5.953252 mm0.234380 in
Basic Load Ratings
C0 - Static Radial Rating
3700 N830 lbf
Ce - Dynamic Radial Rating1 8500 N1910 lbf
Factors
Limiting Speed (Grease)
51000 rpm
Limiting Speed (Oil)
102000 rpm
Specifications
Ball Type
STEEL
Cage Type
CR - Phenolic Outer Land Riding Cage
Bearing Weight
0.036 Kg0.080 lb
Design Units
METRIC
Abutment and Fillet Dimensions
R - Inner Ring "To Clear" Radius2 0.60 mm0.024 in
r - Outer Ring "To Clear" Radius3 0.60 mm0.024 in
da - Inner Ring Backing Diameter
16.4 mm0.650 in
Da - Outer Ring Backing Diameter
28.100 mm1.110 in
______________________________________________________________________________________________________________________________________________________________________________________________________________________________________
#1 (78)
Specifications
| Manufacturer | Timken |
| Model | 3MM201WICRDUL |
| Condition | New |
| Stock Number | Spindle Angular Contact Ball Bearing |
| Country of Origin | United States |
| Material | Steel |
| Width | 10 mm |
| Outside Diameter | 32 mm |
| Bore Diameter | 12 mm |
| Bearings Type | Angular Contact Ball Bearing |
