WENGLOR I12H016 Inductive Sensor with Increased Switching Distance 12mm 10-30VDC
$87.50
Description
WENGLOR I12H016 Inductive Sensor with Increased Switching Distance 12mm 10-30VDC NSFS
This listing is for a high-quality
[WENGLOR I12H016 inductive proximity sensor](https://www.google.com/search?ibp=oshop&prds=pvt:hg,pvo:29,imageDocid:8624042150505045963,headlineOfferDocid:16325009375471643359,productDocid:16325009375471643359&q=product&sa=X&ved=2ahUKEwjm_ZmitbaRAxXkrokEHS9wL1YQxa4PegYIAQgIEAI). These sensors are known for their rugged design and reliable measured values in industrial automation applications.
NSFS – New Surplus Factory Sealed (OEM)
WARRANTY: 120 DAYS
Inductive characteristics
Switching distance 12 mm
Correction factor stainless steel V2A / CuZn / Al 1.04 / 0.54 / 0.53
Mounting type non-flushable
A / B / C / D mounting in mm 20/40/36/14
B1 mounting in mm 0 ... 14
Switching hysteresis <10%
Electronic characteristics
Supply voltage 10 ... 30 V DC
Current consumption (Ub = 24 V) <12 mA
Switching frequency 360 Hz
Temperature drift <10%
Temperature range -40 ... 80 ° C
Discrete output voltage drop <1 V
Switched current digital output 150 mA
Discrete output residual current <100 µA
Short circuit protection Yes
Overload / reverse polarity protection Yes
Protection class III
Mechanical characteristics
Material case CuZn, nickel plated
Protection sign IP67
Connection mode M12 × 1; 4-pole
Technical safety data
MTTFd (EN ISO 13849-1) 3706.54 a
Function
Fault output signaling Yes
Exit
PNP opening contact, closed contact. antivalent
Yes
Specifications
| Manufacturer | wenglor |
| Model | I12H016 |
| Condition | New |
| Stock Number | 363393761231 |
| Sensor Type | INDUCTIVE SENSOR |
| Location | #1-2 |
