NEW KEYENCE PZ-V13 BUILT-IN AMPLIFIER PHOTOELECTRIC SENSOR M12 CONNECTOR

NEW KEYENCE PZ-V13 BUILT-IN AMPLIFIER PHOTOELECTRIC SENSOR M12 CONNECTOR SPECIFICATIONS Model PZ-V13 Type Multi reflective model (M12 connector cable type) Output NPN Detecting distance 5 to 100 mm0.20" to 3.94" (100 x 100 mm3.94" x 3.94"white mat paper)*1 Setting distance 30 to 100 mm1.18" to 3.94" (100 x 100 mm3.94" x 3.94"white mat paper) Light source. Red LED Sensitivity adjustment Automatic push button Response time 1 ms max. Operation mode LIGHT-ON/DARK-ON (switch-selectable) Indicator lamp Output: orange LED, stable operation: green LED Control output 100 mA (40 V) max.Residual voltage: 1 V max. Digital monitor 7-segment, 3-digit red LED Protection circuit Reversed polarity, overcurrent protection, surge absorber Rating Power voltage 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less Power consumption 37 mA max. Environmental resistance Enclosure rating IP67 Ambient light Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max. Ambient temperature -20 to +55 °C -4 to 131 °F (No freezing) Relative humidity 35 to 85 % RH (No condensation) Vibration resistance 10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions Shock resistance 1,000 m/s2, 6 times in each of the X, Y, and Z directions Case material Glass-fiber reinforced plastic Weight Approx. 25 g *1 The detecting distance is obtained with the maximum sensitivity. ____________________________________________________________________________ #1-26
