GROVE GEAR IRONMAN GR-FHMQ818-60-HL-56-16 GEAR REDUCER 60:1 GRF18002262.16 NSMP

$1,150

Description

GROVE GEAR IRONMAN GR-FHMQ818-60-HL-56-16 WORM GEAR REDUCER 60:1 GRF18002262.16 NSMP Technical Specifications Series Code: GR Output Style: HL Input HP: 0.449 Output HP: 0.288 Output Shaft Assembly Code: HL Reducer Style: Worm - Right Angle Mounting Style: Flange Mounted Hollow Output Bore Input RPM: 1,750 Output Key: 1/4 X 2.50 Input Style: C-Face Quill Frame Size: 56C Series Type: Cast Iron 800 Worm Gear Reducers Output Shaft Orientation: HL Output RPM: 29 Keyway: 3/16 X 3/32 Series Style: GR-FHMQ-HL Bore Code: 16 Input Bore (C Face): 0.625 Ratio Range: 60:1 Center Distance (in): 1.75 Service Factor: 1 Shaft Seal Material: Viton Product Type: Right Angle Input Keyway (C Face): 3/16 x 3/32 Input Quill Diameter (in): 0.625 in Input HP @ 1750 RPM: 0.449 Assembly: FHMQ-HL Input Diameter (in): 0.625 in Motor Frame Size: 56C Product Line: GR Series - Ironman Worm Gear Reducers Gear Type: Worm No. of Gear Reductions: Single Thrust Rating - output shaft: 1144 Motor HP Rating: 0.333333 Input Keyway: 3/16 X 1.38 in Output Diameter (in): 1.000 in Ratio: 60:1 Reducer: Worm - Right Angle Model Code: FHMQ818 Series: GR Series - Ironman Worm Gear Reducers Reduction: Single Output Shaft Direction: HL Overhung Load Rating (Output Shaft(lb)): 1,200 lb Output Torque Rating (in-lb): 623 in/lbs Housing Material: Cast Iron Output Shaft: Hollow Bore CONDITION: NSMP - New Surplus Manufacturer Package (OEM) WARRANTY: 120 DAYS SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST. (CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT) ________________________________________________________________________________ BELOW PALLET 242

Specifications

ManufacturerGrove Gear
ModelGR-FHMQ818-60-HL-56-16
ConditionUsed
Stock Number365800994309
Country of OriginUnited States
LOCATIONBELOW PALLET 242
TypeRight Angle Speed Reducer
Shaft OrientationRight Angle
Nominal Ratio60:1
