Murrelektronik 9000-41094-0101000 Mico Pro Flex 4.10 Module New Surplus

Murrelektronik 9000-41094-0101000 Mico Pro Flex 4.10 Module New Surplus Up for sale is a genuine Murrelektronik Mico Pro flex intelligent current monitoring and electronic circuit protection module, part number 9000-41094-0101000. Unlike single-channel versions, this high-density 4-channel modular slice component provides premium, independent diagnostic tracking and overload protection across four separate 12V DC or 24V DC load circuits. It features customizable current configurations spanning from 1A to 10A per channel via direct push-button controls, keeping machine systems highly available and optimizing power distribution inside control panel networks. Technical Specifications - Manufacturer: Murrelektronik GmbH - Product Line: Mico Pro Series - Model Part Number: 9000-41094-0101000 - Model Designation: Mico Pro Flex 4.10 - Component Type: 4-Channel Electronic Circuit Protection Module - Input Operating Voltage Window: 9 to 30 VDC - Nominal Input Voltages: 12 VDC / 24 VDC - Total Bridge Current Capacity: Maximum 40 Amps system full load - Triggering Current Adjustability Profile: 1A to 10A DC per channel (Adjustable in 1A increments) - Channel Load Capacity: Max 10 Amps per individual circuit path - Diagnostics & Warning Indicators: LED-bar warning flash when load exceeds 90% threshold on a channel - Control Signal Integration: 4x CTRL Inputs (Individual channel remote ON/OFF control input) - Diagnostic Feedback: 4x Individual Alarm outputs (Alarm 1 to Alarm 4) for distinct channel error tracking - Connection Methods: Integrated slide bridging network (Input) / Removable green push-in spring clamp terminal blocks (Output) - Terminal Wire Size Compatibility: AWG 24 to 12 (Flexible output wires) - Enclosure Protection Class: IP20 Rating - Operating Temperature Profile: -25 to 55 Degrees C - Mounting Format: Space-saving modular slice designed for standard 35mm DIN rail setups - Standards Compliance: cULus Listed Ind. Cont. Eq. 61RM, CSA 165828, EAC, CE, DNV-GL Approved, RoHS Compliant - Manufacturing Origin: Made in Czech Republic (96114-1.06-1.10) Item Condition - Condition: New Surplus (Open Box / No Retail Packaging). This premium industrial circuit protection module is an entirely unused facility replacement spare that was cataloged and stored safely inside a clean, climate-controlled warehouse facility. It has never been deployed, wired, or energized. - Storage Condition: The housing body, front diagnostic print layouts, and internal side-bridge contacts are in pristine condition with zero wear. - Note on Accessories: Please note that this specific module slice does not include the optional green plastic side protective end panels. It comes with the three removable green terminal block plugs and the matching manufacturer manual. WARRANTY: 120 DAYS SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST. (CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT) SELL YOUR SURPLUS PremiumPLC BUYS ALL TYPES OF NEW AND USED INDUSTRIAL AUTOMATION & MRO SURPLUS ________________________________________________________________________________ 2190
