Allen Bradley 1606-XLP72E DIN Rail Power Supply 24-28V 72W Max Series A

Allen Bradley 1606-XLP72E DIN Rail Power Supply 24-28V 72W Max Series A Brand: Allen-Bradley / Rockwell Automation Series: 1606-XLP Performance Power Supplies Model / Catalog No: 1606-XLP72E (Series A) Type: Compact Switching Mode Power Supply Input Voltage Rating: AC 100-120V / 220-240V (Manual Selector Switch), 50-60Hz, 1.6/0.8A Output Voltage Range: DC 24-28V (Adjustable Potentiometer, Factory Set to 24.5V) Output Current Rating: 3 Amps at 24V DC / 2.6 Amps at 28V DC Maximum Power Capacity: 72 Watts Safety Rating Standard: NEC Class 2 Compliant, Class I Div 2 Hazardous Locations (Groups A, B, C, D) Mounting Configuration: 35mm DIN Rail Mount Features: DC OK Green Status LED, Adjustable Output Trim Pot, Manual Input Voltage Slider, Finger-Safe Terminals Compliance Certifications: cULus Listed, CE, N223, Germanischer Lloyd (GL) Marine Approved Country/Region of Manufacture: China For sale is a pre-owned Allen-Bradley 1606-XLP Compact Series DIN rail switching power supply, catalog number 1606-XLP72E. This heavy-duty automation component converts single-phase AC line voltage into a clean, regulated 24V to 28V DC output stream, delivering up to 72 Watts of continuous power. Designed for industrial deployment, it features a front-mounted 120V/240V input range slider, an adjustable voltage trim dial, and a green DC OK status indicator LED. This module complies with strict NEC Class 2 criteria and is rated for Class I Division 2 hazardous environments. It is ideal for powering PLC racks, HMI screens, sensors, and low-voltage control circuits inside industrial electrical enclosures. Used / Fully Functional. This power supply unit was removed from a working industrial panel environment during system retrofits. The outer black polymer housing, ventilation slots, front selector switch, and rear integrated 35mm DIN rail mounting tabs are fully intact and free of cracks or damage. The face exhibits common signs of standard use, including an ink-marker label ("PWS 3") hand-written on the lower left casing edge from local asset layout mapping. The front and side specification stickers remain entirely legible. The terminal wire clamp paths are clean, rust-free, and mechanically sound. WARRANTY: 90 DAYS SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST. (CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT) SELL YOUR SURPLUS PremiumPLC BUYS ALL TYPES OF NEW AND USED INDUSTRIAL AUTOMATION & MRO SURPLUS _________________________________________________________________________________ 2162
