NEW FESTO ELECTRIC VADM-140-P / 162518 VACUUM GENERATOR W/O FILTER MODULE

NEW FESTO ELECTRIC VADM-140-P / 162518 VACUUM GENERATOR SER. E702 VADM140P MISSING FILTER MODULE 690452 / VADM/VADMI-140/200 Nominal width of Laval nozzle: 1.4 mm Width dimension: 22 mm Type code: VADM Muffler construction type: Closed Mounting position: Any Ejector characteristics: High vacuum Grade of filtration: ⤠40 µm Manual override: Non-detenting Integrated function: Ejector pulse valve, electric Flow control Shut off valve, electric Compressed air filter Non-return valve Vacuum switch Measured variable: Relative pressure Measuring principle: Piezoresistive Switching element function: N/O contact Switching function: Threshold value comparator Symbol: 00991304 Valve function: Closed Reverse polarity protection: for all electrical connections Display type: LED Setting range threshold value: -0.9 bar ... 0 bar Setting range hysteresis: -0.5 bar ... -0.05 bar Setting options: Potentiometer Switching status indication: Optical Operating pressure: 2 bar ... 8 bar Max. vacuum: 85 % Nominal operating pressure: 6 bar Air supply time at nominal operating pressure: 0.69 s DC operating voltage range: 21.6 V ... 26.4 V Duty cycle: 100% Switching output: PNP Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4] Information on operating and pilot media: Operation with oil lubrication not possible CE marking (see declaration of conformity): As per EU EMC directive Corrosion resistance class (CRC): 2 - Moderate corrosion stress Temperature of medium: 0 °C ... 60 °C Degree of protection: IP65 Ambient temperature: 0 °C ... 50 °C Certification RCM compliance mark c UL us - Recognized (OL) Product weight: 300 g Pressure measuring range: 0 bar ... 1 bar Electrical connection 4-pin M8x1 Plug Type of mounting Optionally: With through-hole With internal thread Pneumatic connection 1: G1/8 Pneumatic connection 3: Pneumatic muffler integrated Vacuum connection: G1/4 Note on materials Free of copper and PTFE RoHS-compliant Seals material: NBR Female nozzle material: Brass, nickel-plated Compressed air filter material: PA Material of filter housing: PC Housing material: Wrought aluminum alloy Muffler material PE POM Material of piston: POM Material of jet nozzle: Brass, nickel-plated
