NEW POWER TEN P63C-10660D P63C SERIES VARIABLE POWER SUPPLY 10V 660A 10kW

NEW POWER TEN P63C-10660D P63C SERIES VARIABLE POWER SUPPLY 10V 660A 10kW Output: 10V, 660A, 50mV Ouput P-P Ripple Input Voltage: 190-253 VAC, 47-63 Hz Input Current @ 208 VAC (Typical): At 10.0 kW Output: 41 A (Operates from Delta or Wye Source) Dimensions: 19" (W) X 5.25" (H) X 22" (D) AC Input Interface: 3 wire + GND (#10-32 threaded studs) (208 VAC) DC Output Interface Control/Monitor Interface: DB 25-pin female connector Regulation (Line or Load) Voltage: 0.1% of maximum rated output Current: 0.5% of maximum rated output Transient Response A 30% current step load will recover to within ±2% of set voltage within 10 msec. Stability ñ0.05% of set point per 8 hours after 30 minutes warm-up at fixed line, load and temperature. Temperature Coefficient 0.02%/°C of rated output voltage 0.03%/°C of rated output current Operating Temperature 0 to +50ð C, No derating Storage Temperature -20 to +70ðC Cooling Internal fans Controls (Front Panel) On/Off switch, DC volts adjust, DC amps adjust, OVP preset adjust (limit set) Meters/Indicators LCD DC voltmeter, ammeter and OVP limit set. LED indicators for voltage mode, current mode. OVP fault and fault Built-In Protection Over Voltage, Current limit Fold back, Over Temperature, Brown Out, Turn On Surge Limit, Slow Start Remote Control/Monitor (Rear Panel) On/Off control via contact closure, 6-120 VDC, TTL or CMOS switch, output voltage and current monitor, OVP limit set, summary fault status on P60 Series. Remote Programming (Voltage (0 to 100%) Current (0 to 100%)): Resistive: 0-5K ohms 0-5K ohms Voltage: 0-5 VDC or 10 VDC 0-5 VDC or 10 VDC Optional IEEE 488.2 and RS 232 Programming with SCPI protocol Remote Sensing: Terminals provided to sense output voltage at load Operational Features: Master/Slave, Series, Parallel CONDITION: NEW IN CRATE WARRANTY: 120 DAYS _____________________________________________________________________________________ UPALLET/A6
