Schneider Electric LRD07 TeSys 034677 LRD Thermal Overload Relay, 1.6-2.5A, NSMP

Schneider Electric LRD07 TeSys 034677 LRD Thermal Overload Relay, 1.6-2.5A, NSMP Item Specifics Brand: Schneider Electric Model: LRD07 Product Range: TeSys LRD Amperage Range: 1.6 A to 2.5 A Number of Poles: 3 Mounting Type: Direct mounting under 3-pole contactor (e.g., LC1D09, LC1D12, LC1D18, LC1D25, LC1D32, LC1D38) or independent mounting with adapter plate (LA7D07) Control Voltage Type: AC/DC Reset Type: Manual and Automatic Main Circuit Voltage Rating: Up to 600 VAC Standards: IEC 60947-4-1, UL 508, CSA C22.2 No 14 Application: Motor Protection, Industrial Control Item Description This is a Schneider Electric LRD07 TeSys LRD Thermal Overload Relay , designed to provide reliable and accurate overcurrent protection for 3-phase AC motors. This relay offers an adjustable current range of 1.6 to 2.5 Amps . It is part of the robust TeSys series, known for its high performance and safety features. Key Features: Adjustable Range: Easily set the precise current trip point between 1.6A and 2.5A. Integrated Protection: Features differential protection against phase failure. Flexible Mounting: Designed for direct connection to compatible Schneider Electric TeSys D contactors, creating a seamless motor starter solution. Reset Options: Includes both manual and automatic reset functions. Safety & Compliance: UL Listed, CSA Certified, and CE marked for global industrial use. CONDITION: NSMP - New Surplus Manufacturer Package (OEM) WARRANTY: 120 DAYS SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST. (CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT) ________________________________________________________________________________ T76
