AMETEK B/W Controls 1500-F-L1-S8-OC-X Liquid Level Control Relay 120/360V 1F1D0A

AMETEK B/W Controls 1500-F-L1-S8-OC-X Liquid Level Control Relay 120/360V 1F1D0A This listing is for an AMETEK B/W Controls Series 1500 Induction Relay (Catalog No. 1500-F-L1-S8-OC-X). This floatless liquid level control system is designed for high-reliability industrial applications, utilizing the conductivity of the liquid to complete a sensing circuit. This specific model is an open chassis unit, ideal for mounting within an existing control panel or enclosure. Technical Specifications: Brand: AMETEK / B/W Controls Warrick Model: 1F1D0A Full Model Number: 1500-F-L1-S8-OC-X Contact Arrangement (F): 3 Normally Open (N.O.) load contacts Primary Line Voltage (L1): 110â120 VAC, 50/60 Hz (Terminals 3 & 4) Secondary Coil Voltage (S8): 360 VAC (Terminals 7 & 8) â Optimized for fresh water applications Enclosure Type (OC): Open Chassis (no external housing included) Additional Options (X): None Contact Rating: 25 Amps Resistive at 120/240/480 VAC or 1 HP single phase at 120/240 VAC Power Consumption: 9 Volt-Amperes Maximum Operating Temperature: -20°F to 150°F (-28.8°C to 65.5°C) Origin: Made in U.S.A. (Clawson, Michigan) CONDITION: NSMP - New Surplus Manufacturer Package (OEM) WARRANTY: 120 DAYS SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST. (CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT) SELL YOUR SURPLUS PremiumPLC BUYS ALL TYPES OF NEW AND USED INDUSTRIAL AUTOMATION & MRO SURPLUS ________________________________________________________________________________ 3158
