TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB

TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB Dimensions d - Bore 12.00 mm 0.4724 in D - Outer Diameter 32.00 mm 1.2598 in Bearing Width 10.00 mm 0.3937 in Contact Angle 25 º do - Ball Diameter 5.953252 mm 0.234380 in Basic Load Ratings C0 - Static Radial Rating 3700 N 830 lbf Ce - Dynamic Radial Rating1 8500 N 1910 lbf Factors Limiting Speed (Grease) 51000 rpm Limiting Speed (Oil) 102000 rpm Specifications Ball Type STEEL Cage Type CR - Phenolic Outer Land Riding Cage Bearing Weight 0.036 Kg 0.080 lb Design Units METRIC Abutment and Fillet Dimensions R - Inner Ring "To Clear" Radius2 0.60 mm 0.024 in r - Outer Ring "To Clear" Radius3 0.60 mm 0.024 in da - Inner Ring Backing Diameter 16.4 mm 0.650 in Da - Outer Ring Backing Diameter 28.100 mm 1.110 in ______________________________________________________________________________________________________________________________________________________________________________________________________________________________________ #1 (78)
