WENGLOR I12H016 Inductive Sensor with Increased Switching Distance 12mm 10-30VDC

WENGLOR I12H016 Inductive Sensor with Increased Switching Distance 12mm 10-30VDC NSFS This listing is for a high-quality WENGLOR I12H016 inductive proximity sensor . These sensors are known for their rugged design and reliable measured values in industrial automation applications . NSFS â New Surplus Factory Sealed (OEM) WARRANTY: 120 DAYS Inductive characteristics Switching distance 12 mm Correction factor stainless steel V2A / CuZn / Al 1.04 / 0.54 / 0.53 Mounting type non-flushable A / B / C / D mounting in mm 20/40/36/14 B1 mounting in mm 0 ... 14 Switching hysteresis <10% Electronic characteristics Supply voltage 10 ... 30 V DC Current consumption (Ub = 24 V) <12 mA Switching frequency 360 Hz Temperature drift <10% Temperature range -40 ... 80 ° C Discrete output voltage drop <1 V Switched current digital output 150 mA Discrete output residual current <100 µA Short circuit protection Yes Overload / reverse polarity protection Yes Protection class III Mechanical characteristics Material case CuZn, nickel plated Protection sign IP67 Connection mode M12 à 1; 4-pole Technical safety data MTTFd (EN ISO 13849-1) 3706.54 a Function Fault output signaling Yes Exit PNP opening contact, closed contact. antivalent Yes
